24-Channel TTL Digital I/O Low-profile Universal PCI Card (PCI-1757UP-AE)
by Advantech
•Part #: PCI-1757UP-AE
View Detailed Description
$125.00
Call for Availability
Due to supply chain inconsistencies, our team will need to verify availability before we can add this item to your cart. Click here to call.
PCI-1757UP is a 24-channel digital I/O low profile PCI card that meets the PCI standard REV.2.2 (universal PCI expansion card). The card also works with 3.3 V and 5 V PCI slots, and provides you with 24 parallel digital input/output channels that emulate mode 0 of the 8255 PPI chip. However, the buffered circuits offer a higher driving capability than the 8255.
- Low profile PCI form factor
- Universal PCI bus
- 24 TTL level digital I/O channels
- Emulates mode 0 of 8255 PPI
- Buffered circuits provide higher driving capability
- I/O configurable by software or on board DIP switch
- Keeps port I/O settings and digital output states after hot resets
- BoardID™ switch
- Convenient DB-25 connector, Dry/wet contact support
| General | Power Consumption | Typical: 5 V @ 200 mA |
| I/O Connectors | D-SUB 25-pin female connector | |
| Operating Temperature | 0~70° C (32~158° F) | |
| Bus | PCI | |
| Dimensions | 119.91 x 64.41 mm | |
| OS Support | 32-bit/64-bit Windows 7/8/10, and Linux | |
| Programming Language | C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt | |
| TTL DI/O | Input Channels | 24 (shared) |
| Output Channels | 24 (shared) |
