Compact Embedded Chassis with 250 Watt PSU and HDD Bay (IPC-3012-25ZE)
by Advantech
•Part #: IPC-3012-25ZE
View Detailed Description
$189.00
Call for Availability
Due to supply chain inconsistencies, our team will need to verify availability before we can add this item to your cart. Click here to call.
Compact Chassis for PICMG 1.3 Half Size SHB
- Compact chassis with two expansion slot
- Support High Computing PICMG 1.3 Half Size SHB
- Support two 2.5" HDD for RAID 0,1 configure
- Optional bi-direction mounting on wall or workbench
- Top cover with thumb screw for easy maintenance
| Cooling | Air Filter | Yes |
| Fan | 2 ( 6 cm / 27 CFM) | |
| Disk Drive Bay | 2.5" Internal | 2 |
| Environment | Operational Temperature | 0 ~ 40° C (32 ~ 104° F) |
| Non-Operational Temperature | -20 ~ 60° C (-4 ~ 140° F) | |
| Operating Humidity | 10 ~ 85% @ 40° C, non-condensing | |
| Operating Vibration (5 ~ 500 Hz) | 1 Grms | |
| Non-Operating Vibration (5 ~ 500 Hz) | 2 G | |
| Shock | 10 G (with 11 ms duration, half sine wave) | |
| Front I/O Interface | USB | 2 |
| Miscellaneous | LED Indicators | Power, HDD |
| Control | Power Switch | |
| Physical Characteristics | Weight | 3.24 kg ( 7.14 lb ) |
| Dimensions (W x H x D) | 232 x 90 x 232 mm (9.1 x 3.5 x 9.1) |
