CHASSIS, ACP-4010MB Bare Chassis w/SMART Control BD (ACP-4010MB-00BE)
by Advantech
•Part #: ACP-4010MB-00BE
View Detailed Description
$238.00
Call for Availability
Due to supply chain inconsistencies, our team will need to verify availability before we can add this item to your cart. Click here to call.
- Supports either an ATX/CEB/EEB single/dual processors motherboard or a PICMG backplane with up to 15 slots
- Supports one or two systems in a single chassis
- Shock-resistant disk drive bay design holds up to two 5.25" and two 3.5" disk drives
- LED indicators and alarm notification for system fault detection and network connection
- Low noise system fans with fan speed control
- Built-in Intelligent System Module enables whole system fan control and remote manageability
| Cooling | System Fan | 2 (12 cm / 85 CFM each) |
| Air Filter | Yes | |
| Drive Bay | 5.25 External Bay | 2 |
| 3.5 External Bay | 1 | |
| 3.5 Internal Bay | 1 | |
| Environment | Operational Temperature | 0 ~ 40° C (32 ~ 104° F) |
| Non-Operational Temperature | -20 ~ 60° C (-4 ~ 140° F) | |
| Operating Shock | 10 G (with 11 ms duration, half sine wave) | |
| Operating Humidity | 10 ~ 85% @ 40° C, non-condensing | |
| Non-Operating Humidity | 10 ~ 95% @ 40° C, non-condensing | |
| Operating Vibration (5 ~ 500 Hz) | 1 Grms | |
| Non-Operating Vibration (5 ~ 500 Hz) | 2 G | |
| Non-Operating Shock | 30 G | |
| Front I/O Interface | USB2.0 | - |
| Intelligent System Module | Remote Monitoring | CPU/System fan speed , CPU/System temperature , motherboard voltage |
| Miscellaneous | LED Indicators | Power, HDD, temperature, fan, LAN1, and LAN2 |
| Rear Panel | One 9-pin D-Sub opening | |
| Physical Characteristics | Weight | 16.6 kg (36.5 lb) |
| Dimensions (W x H x D) | 482 x 177 x 479 mm (19" x 7" x 18.9") |
